Wedge Clamps; Wedge Clamp Style: Vise; Single or Double Wedge: Single; Screw Thread Size: 5/8-11 in; Machinable: Yes; Holding Force: 13227.74 lb; Overall Width: 2.64 in; 67.06 mm; Base Height: 28.96 mm; 1.14 in; Base Width: 2.64 in; 67.06 mm; Base Depth:
Item #: 02004026
Brand: Yuasa
Model #: 215-203
Product Specifications
| Wedge Clamp Style | Vise |
| Single or Double Wedge | Single |
| Screw Thread Size | 5/8-11 in |
| Machinable | Yes |
| Holding Force | 13227.74 lb |
| Overall Width | 2.64 in; 67.06 mm |
| Base Height | 28.96 mm; 1.14 in |
| Base Width | 2.64 in; 67.06 mm |
| Base Depth | 41.91 mm; 1.65 in |
| Jaw Hardness | 30 to 34 |
| Minimum Jaw Spread | 2.64 in; 67.06 mm |
| Maximum Jaw Spread | 75.95 mm; 2.99 in |
| Projection From Base | 5.08 mm; 0.2 in |
| Base Height (mm) | 28.96 |
| Base Width (mm) | 67.06; 2.64 in; 67.06 mm |
| Base Depth (mm) | 41.91 |
| Minimum Jaw Spread (mm) | 67.06 |
| Optimum Jaw Spread (mm) | 71.12 |
| Optimum Jaw Spread (Decimal Inch) | 2.8000 |
| Maximum Jaw Spread (mm) | 75.95 |
| Projection From Base (mm) | 5.08 |
| Overall Width (mm) | 67.06; 2.64 in; 67.06 mm |
| Includes | Mounting Screw |
