Tungaloy - Torx Cap Screw for Indexable Drilling - M3x0.5 Thread, For Use with Clamps & Inserts
Item #: 01689876
Brand: Tungaloy
Model #: 5691810
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Drill Style | DFS |
| Drill Diameter (mm) | 44.45 |
| Drill Diameter (Inch) | 1-3/4 |
| Drill Diameter (Decimal Inch) | 1.7500 |
| Maximum Drill Depth (Inch) | 5-1/4 |
| Shank Type | Flange |
| Shank Diameter (Decimal Inch) | 1.5000 |
| Shank Diameter (Inch) | 1-1/2 |
| Cutting Direction | Right Hand |
| Through Coolant | Through Coolant |
| Drill Depth by Diameter Ratio | 3xD |
| Toolholder Material | Steel |
| Number of Drill Inserts | 2 |
| Overall Length/Projection (mm) | 273.05 |
| Overall Length/Projection (Decimal Inch) | 10.7500 |
| Insert Compatibility (Outside or Peripheral) | SPPX15T5.. |
| Insert Compatibility | DFT0704.. |
| Flute Length (mm) | 155.00 |
| Flute Length (Decimal Inch) | 6.1024 |
| Body Length (Decimal Inch) | 7.0000 |
| Body Length (mm) | 177.80 |
| Shank Length (mm) | 95.25 |
| Shank Length (Decimal Inch) | 3.7500 |
