Hydraulic Tool Chuck: HSK63A Taper Shank, 3/4" Hole
Item #: 67203356
Brand: Accupro
Model #: 1527343
Product Specifications
| Shank Type | Taper |
| Connection Size | HSK63A |
| Taper Size | HSK63A |
| Hole Diameter (Inch) | 3/4 |
| Nose Diameter | 1-15/32 |
| Nose Diameter (Mm) ( - 2 Decimals) | 37.50 |
| Projection (mm) | 90.000 |
| Projection | 3-17/32 |
| Clamping Depth (mm) | 51.00 |
| Balanced To Rpm | 25000 |
| TIR (Decimal Inch) | 0.000010 |
| Through Coolant | Yes |
| Overall Length (Decimal Inch) | 5.8268 |
| Body Diameter (Decimal Inch) | 1.9690 |
| Additional Information | Replaces SKU 56509680 |
| UNSPSC Code | 27112800 |
| Shank Type | Taper |
| Connection Size | HSK63A |
| Taper Size | HSK63A |
| Hole Diameter (Inch) | 3/4 |
| Nose Diameter | 1-15/32 |
| Nose Diameter (Mm) ( - 2 Decimals) | 37.50 |
| Projection (mm) | 90.000 |
| Projection | 3-17/32 |
| Clamping Depth (mm) | 51.00 |
| Balanced To Rpm | 25000 |
| TIR (Decimal Inch) | 0.000010 |
| Through Coolant | Yes |
| Overall Length (Decimal Inch) | 5.8268 |
| Body Diameter (Decimal Inch) | 1.9690 |
| Additional Information | Replaces SKU 56509680 |
| UNSPSC Code | 27112800 |
| MSC Part # | 67203356 |
| Mfr Part # | 1527343 |
